Name: iFlight Blitz BEC 5V/12V Power Supply Module
Brand: iFlight
SKU: FG-EA-IF-BEC
Availability: OutOfStock

Description

The BLITZ BEC features step-down switch mode, high-efficiency synchronous rectification, and the ability to step down from an input voltage of up to 35V to a low output stable voltage, which makes it ideal for step-down voltage applications.

It offers a very compact solution to achieve 2A/3A output current over a wide input supply voltage (6 to 35V).

* Short connect ON-12V, the output voltage is 12V. When disconnected, the output voltage is 5V.

* If there is sparking phenomenon when the power is turned on, it is recommended that the input voltage should not exceed 26V.

FEATURES:

Step-down switch mode
High-efficiency synchronous
Wide 5V to 36V Input voltage range
The voltage output can be 5V or 12V adjustable. (default 5V)

PACKAGE INCLUDES:

1 x iFlight Blitz BEC Module – 5V/12V Output
1 x Cable Set

Additional information

Weight	4.5 g

SPECIFICATIONS

Specification	Details
Input voltage	2-8S(5-35V)
BEC Output	5V/3A, 12V/2A (default 5V/3A)
Conversion efficiency	the average efficiency of output 12V is above 92%, and the average efficiency of output 5V is above 88%.
Size	12144.5mm
Pins distance	2.55mm
Weight	1.8g

PACKAGE INCLUDES

1 x iFlight Blitz BEC Module – 5V/12V Output
1 x Cable Set
