Newly upgraded Durable 5.8G SMA RHCP V2 Antenna for Analog or Digital FPV.
The perfect upgrade part for your DJI Air Unit to avoid buying fragile stock antennas again and again…
Use RP-SMA LHCP (Left Hand Polarization) for DJI Digital FPV! Default antennas are LHCP and Goggle Antennas are LHCP, both sides need to match!
FEATURES:
A hexagonal shape for enhanced durability and a right-angle design for convenient fixation.
Utilizes ultrasonic welding technology to ensure a lightweight yet secure antenna attachment.
Achieves higher consistency in antenna gain, thereby improving device performance and stability.
RHCP Specifications:
Model: Albatross 5.8GHz RHCP SMA FPV Antenna
Interface: RHCP SMA
Frequency range: 5.3GHz-6GHz
Max Gain: 2.65dBi (5695MHz)
MIN Gain: 2.06dBi (5362MHz)
AVG Gain: 2.4dBi
MAX VSWR: 1.76（5917MHz）
MIN VSWR: 1.46（5621MHz）
AVG VSWR: 1.75
MAX radiation efficiency: 86%（5436MHz）
MIN radiation efficiency: 76%（5917MHz）
AVG radiation efficiency: 83%
Polarization: RHCP
Cross polarization suppression: -25dB
Axial Ratio：≤3
Cable: RG141
Weight: 7g
Size: Total length: 85mm, cable length:60mm
PACKAGE INCLUDES:
- 1 x iFlight Albatross V2 60mm 5.8Ghz Antenna – RHCP SMA
