Amass XT60H Connector (1 Pair)
The best battery connectors on the market just got better with the development of the XT60H, also called the XT60+.
The new XT60H features snap on insulating end caps which provide extra grip and heart-shrink free installation. They also have a design change which is far more user-friendly for connection and disconnection with an improved integrated grip area.
Like the original XT60, this connector is made from high-temp nylon with gold plated connectors so the XT60H continues to provide an excellent high-amp connection for applications up to 60A.
This is a genuine AMASS connector. The XT60-H is backwards compatible with original XT60 connectors so you can use them straight away.
SPECIFICATIONS:
- Brand Name: Amass
- Item Name: XT60+
- Body Material: Gold-plated copper
- Internal Material: Nylon/PA
- Internal Resistance: 0.8mΩ
- Max. RC/MC: 60A/100A
- Weight: 3.50g/pc
- Pulling Force/600: 3kg
- Temperature Resistance: -20°C~120°C
- Recommend Use: 1000 times
- Recommend Cable Spec.: 12AWG
- Recommend Soldering Spec.: 480°C/4S
- Quantity: 1 pair
PACKAGE INCLUDES:
- 1 x Amass XT60H Male plug
- 1 x Amass XT60H Female plug
