The TBS Source One V5.1 5″ Frame Kit is a wide-stance, X configuration frame, and popular frame kit for freestyle or free-range acrobatic flying! It is built to withstand harsh crashes and abuse. It fits and protects all the classic FPV components and is optimized for lightweight. The Source One is a perfect everyday workhorse for casual FPV flying and competitive freestyle.
ABOUT THE PROJECT
The Source One project is a first-of-its-kind collaborative FPV frame project initiated by Team BlackSheep. The frame is donated to the community to empower creators and makers to integrate best practices and current trends into a continuously manufactured product. In return, TBS is allowing the local FPV community and distribution networks to have access to a cheap but good frame to help them compete in an increasingly predatory marketplace!
GET INVOLVED!
- 3D Printed Parts (STL) https://github.com/tbs-trappy/source_one/tree/master/3D%20Print%20Accessories
- 3D Printed files on Thingiverse: https://www.thingiverse.com/tag:sourceone
- Build Guide: https://oscarliang.com/how-to-build-fpv-drone/
- Project discussion: https://discordapp.com/invite/ZJGkHwF
- Project files: https://github.com/tbs-trappy/source_one
The recommended items were put together by the pilots at FpvGuru. We strive for reliability and high quality in all of their selections, which may cost a bit extra but it allows you to enjoy the frame much more!
BUDGET BUILD
- FC/ESC Stack: SpeedyBee F405 V4 55A Stack
- Motors: 4x iFlight XING-E Pro 2207 1800KV Motor
- Camera: Caddx Ratel 2 Analog FPV Camera
- VTX: Rush Tank Ultimate MINI 5.8GHz 20×20 VTX
- Antenna: iFlight Albatross V2 5.8Ghz Antenna
- Props: Gemfan Hurricane 51466 V2 3-Blade Propeller
- GPS: TBS M10Q GPS Glonass
- Lipo Battery: CNHL Black Series V2.0 1300mAh 22.2V 6S 130C Lipo
PRO FREESTYLE BUILD
- FC/ESC Stack: TBS Lucid Pro Stack 6S 60A
- Motors: 4x iFlight XING-E Pro 2207 1800KV Motor
- Camera: Caddx Ratel 2 Analog FPV Camera
- VTX: TBS Unify Pro32 HV (MMCX)
- Antenna: TBS Triumph Pro Antenna (SMA)
- Props: Gemfan Hurricane 51466 V2 3-Blade Propeller
- GPS: TBS M10Q GPS Glonass
- Buzzer: JHE20B Finder 100dB Buzzer
- Lipo Battery: CNHL Black Series V2.0 1300mAh 22.2V 6S 130C Lipo
PACKAGE INCLUDES:
- 4x OD 5mm M3 30mm standoff
- 4x OD 5mm M3 22mm standoff
- 1x Screw & Standoff set
- 16x M3x10 Allen screw
- 8x M3 press insert nut
- 4x M3x12 Allen screw
- 4x M3x14 Allen screw
- 2x Camera Plate
- 1x Bottom Plate
- 1x Middle Plate
- 1 Arms spacer
- 1x Top Plate
- 1x Brace
- 4x Arms
